Cutting Width |
72 in |
Fan Steel Thickness |
13/32 in |
Cutting Height |
27 in |
PTO Range |
25-65 HP |
Cutting Edge |
1/2" x 4" hardened bolt-on replacement |
3-Point Hitch |
CAT I & II |
Auger Diameter |
17.5 in |
PTO Speed |
540 RPM |
Auger Thickness |
5/16 in |
Gearoil Capacity |
1.22 quart (1.15L) |
Auger Tube Diameter |
2 3/4 in |
Gearoil Type Recommended |
85W-90 |
Fan Type |
4 Blade Fan Style |
Packing Size (LxWxH) |
73 x 45 x 33 in |
Fan Diameter |
24 in |
Weight (N.W/G.W.) |
842/919 lbs |
Fan Depth |
7 in |
|
|
WARNlNG: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s) for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
