Metal Lathe Machine 11'' x 30'' High Precision Benchtop Brushless Motor 0-2000 RPM Variable Speed Metal Working Machine 2HP Small Lathe without Stand

Name: Metal Lathe Machine 11'' x 30'' High Precision Benchtop Brushless Motor 0-2000 RPM Variable Speed Metal Working Machine 2HP Small Lathe without Stand
Brand: MechMaxx
SKU: 500007
Price: 3699.0 USD
Availability: InStock
Rating: 5.0 (1 reviews)

Metal Lathe Machine 11'' x 30'' High Precision Benchtop Brushless Motor 0-2000 RPM Variable Speed Metal Working Machine 2HP Small Lathe without Stand

$369900

$3,999.00

Save $300

FREE SHIPPING, Liftgate service available for an additional fee at checkout.

Details

Delivery in 10 - 15 Business Days

Details

Model : 1130V

In Stock

1130V 0831V 0831VD 1030V 1030VD 1130VD 1440G 1440GV 1030VC COMBO 1130VC COMBO CLM1620 COMBO CLM1632 COMBO

Payment:

315-750-4008

Sales Contact Number

sales@mechmaxx.com

Sales Contact Email

Frequently Bought Together

Storage Stand For Metal Lathe Machine 1130 Serial （SKU:500007）(SKU:500008) (SKU:500102) Without Oiltray

8-1/4"x33'' Industrial Benchtop Mill Drill Machine Brushless Motor, Variable Speed, R8 Spindle, 2 HP, 110V, Compact Milling Drilling Tool for Garage Shop, DIY Metalworking without Stand

1.5HP 7‘’x 27-1/2‘’ Benchtop Mini Mill Drill Machine, Variable Speed, R8 Spindle, Brushless Motor, 110V, Compact Milling Drilling Tool for Garage Shop, DIY Metalworking without Stand

Storage Stand For Metal Lathe Machine 1130 Serial （SKU:500007）(SKU:500008) (SKU:500102) Without Oiltray $46900 $499.00

8-1/4"x33'' Industrial Benchtop Mill Drill Machine Brushless Motor, Variable Speed, R8 Spindle, 2 HP, 110V, Compact Milling Drilling Tool for Garage Shop, DIY Metalworking without Stand $279900 $3,199.00

1.5HP 7‘’x 27-1/2‘’ Benchtop Mini Mill Drill Machine, Variable Speed, R8 Spindle, Brushless Motor, 110V, Compact Milling Drilling Tool for Garage Shop, DIY Metalworking without Stand $259900 $2,799.00

Total Price

$

Product Overview

Powerful 2 HP Motor: The lathe is equipped with a 2 HP motor, providing consistent and reliable power to handle a wide variety of turning operations. The 110V, single-phase motor is perfect for both hobbyists and professionals.
Variable Spindle Speeds: Featuring variable spindle speeds from 0–2000 RPM, the lathe allows precise control for different materials and applications. Whether you're working with metals or softer materials, you can adjust the speed to suit your needs.
One-Piece Spindle for Increased Precision:
Unlike traditional two-piece spindles, this lathe features a one-piece spindle that ensures greater rigidity, higher precision, and more stable operation. The MT#5 spindle taper and 1-1/2" (38mm) spindle bore further enhance its capability to handle larger workpieces.
Precision Threading: Capable of cutting both inch threads (8–56 TPI) and metric threads (0.4–3.5mm), this lathe is versatile for a variety of threading applications. The thread dial indicator simplifies threading setups, ensuring consistent and accurate threads every time.
Heavy-Duty Build: The 7" (180mm) bed width and solid construction ensure better stability during machining. The larger spindle bore and MT#5 spindle taper further improve performance and versatility for a wide range of tasks.
Heavy-Duty Construction: The 7" (180mm) bed width and solid build provide better stability and precise machining.

Product manual (PDF)

11'' x 30'' Metal Lathe Machine 1.0.pdf

Product Features

High-Precision 3-Jaw Chuck

This 5" 3-jaw chuck offers a strong 1.5" clamping range, ensuring secure grip and minimal runout. Designed with a MT5 spindle taper, it provides a tight, stable fit for accurate turning operations. Perfect for both small and large components, this chuck combines strength, durability, and precision.

Electronic Control with Stepless Speed Adjustment

The high-quality electronic control system provides stepless speed adjustment, allowing for smooth, continuous speed changes for different workpieces. With a clear speed display, you can easily monitor and adjust settings, ensuring precise control and flexibility for all your machining tasks. Effortlessly switch between tasks and materials, and achieve the best results every time.

High-Precision Tool Post with Adjustable Features

This tool post is designed for precision and versatility, offering a maximum tool bit size of 15/32" for a wide range of cutting tasks. With a 5-3/4" cross slide travel and 3-3/8" compound slide travel, it ensures smooth, accurate movements for detailed machining. The 60° tool post tray rotation allows for easy adjustment and optimal positioning of tools, enhancing flexibility and precision in every operation.

Adjustable Carriage Stop for Precise Control

This adjustable carriage stop ensures accurate and repeatable positioning, enhancing precision in machining operations. Easily adjustable, it allows quick setup for consistent cutting lengths, improving efficiency and reducing errors during long production runs. Perfect for maintaining uniformity across multiple pieces, this tool provides reliable performance with every pass.

Quick-Lock Tailstock with Durable Aluminum Alloy Construction

This tailstock features a quick-lock design for fast, secure adjustments with minimal effort. Made from high-quality aluminum alloy, it offers durability while reducing weight. The streamlined design maintains strength without the excess material, providing an efficient and user-friendly solution for precise operations.

Precision Handwheel with Fine Adjustment

The handwheel allows for fine adjustments with precision control, perfect for tasks requiring high accuracy. Whether you're fine-tuning feed rates or making detailed cuts, this feature ensures smooth and exact movements for precise machining results.

Safety Mechanisms with Power Disconnect

To ensure operator safety, this machine features automatic power cut-off when the chuck guard or gearbox cover is removed. This protective design prevents the machine from operating during maintenance or adjustments, reducing the risk of accidents and ensuring a safer working environment.

Automatic Longitudinal and Cross Feed Support

Equipped with automatic feed in both longitudinal and cross directions, this lathe allows for smooth, hands-free cutting operations. It enhances precision and consistency while reducing operator effort—ideal for threading, facing, and extended turning tasks where surface finish and accuracy matter most.

Thread Dial Indicator for Precision Thread Cutting

The thread dial indicator enables accurate thread cutting by providing precise control over the feed rate. It helps synchronize the carriage with the leadscrew, allowing for smooth threading and reducing the chances of misalignment. While it doesn’t directly eliminate vibrations, its role in ensuring accurate cuts helps minimize errors that could lead to instability, enhancing the overall cutting quality and stability.

Motor	2 HP, 110V, Single-Phase, 20A, 60HZ
Swing Over Bed	11-2/5"(290mm)
Swing Over Cross Slide	7-1/4"(185mm)
Swing Over Saddle	5-3/4"(147mm)
Distance Between Centers	29-1/2"(750mm)
Bed Width	7"(180mm)
Spindle Bore	1-1/2" (38 mm)
Spindle Mount	D1-4
Spindle Type	One-piece Spindle
Spindle Taper	MT#5
Tailstock Taper	MT#3
Tailstock Quill Travel	3-1/8"(85mm)
Cross Slide Travel	5-3/4"(147mm)
Compound Slide Travel	3-3/8"(86mm)
Carriage Travel	27-1/2" (700 mm)
Spindle Speeds	0–2000 RPM
Number of Speed Ranges	Variable
Longitudinal Feeds	0.017-0.25mm/R(0.0007-0.0098 in./rev.)
Transverse Feed Rate	0.07-0.53mm/r(0.0027-0.02in./rev)
Leadscrew Size & Pitch	20mm(8TPI)
Threading Capacity - Inch	8-56TPI(21KIDS)
Threading Capacity - Metric	0.4-3.5 mm(12kids)
Maximum Tool Bit Size	15/32''(12mm)
Thread Dial Indicator	YES
Overall Dimensions	59" X 31" X 30"(1400X750X740MM)
N.W/G.W	517/572lbs(235/260kg)
