SKU: 150168HMAX

| Model: SM-36HMAX

36" MAX Portable Sawmill, 25HP 688cc HONDA GX690 V-Twin Engine, 35" Board Width, 20' Track Length, (10 x Blades Included), SM-36HMAX

Name: 36" MAX Portable Sawmill, 25HP 688cc HONDA GX690 V-Twin Engine, 35" Board Width, 20' Track Length, (10 x Blades Included), SM-36HMAX
Brand: MechMaxx
SKU: 150168HMAX
Price: 6699.0 USD
Availability: InStock
Rating: 4.91 (951 reviews)

$669900

$7,999.00

Save $1,300

FREE SHIPPING, Liftgate service available for an additional fee at checkout.

Details

Estimated to ship by Feb 10, 2026. Date is subject to change due to transit delays.

Details

Engine : HONDA

HONDA ZONSEN (BEST SELLER)

Payment:

315-750-4008

Sales Contact Number

sales@mechmaxx.com

Sales Contact Email

Frequently Bought Together

Log Loading Ramp Kit for Sawmill Trailer , SM-36MAX; SM-36HMAX

SM-36MAX; SM-36HMAX Trailer Combo Kit (Trailer Hitch; Torsion Axle; Tire)

SM-36MAX; SM-36HMAX Trailer Primary Sub-Frame, 20' Track Length

( 1 Pack / 2 Pcs ) Belt for Portable Sawmill, SM-32; SM-36MAX (SKU: 150167; 150167K4; 150167D6; 150167K6; 150167H6; 150168MAX; 150168HMAX)

( 1 Pack / 1 Pcs ) Sawmill Cover - Custom Fitted for 36" MAX Portable Sawmill, SM-36MAX; SM-36HMAX (150168MAX; 150168HMAX)

36" MAX Portable Sawmill, 25HP 688cc HONDA GX690 V-Twin Engine, 35" Board Width, 20' Track Length, (10 x Blades Included), SM-36HMAX $669900 $7,999.00

Log Loading Ramp Kit for Sawmill Trailer , SM-36MAX; SM-36HMAX $59999

SM-36MAX; SM-36HMAX Trailer Combo Kit (Trailer Hitch; Torsion Axle; Tire) $59900

SM-36MAX; SM-36HMAX Trailer Primary Sub-Frame, 20' Track Length $109900

( 1 Pack / 2 Pcs ) Belt for Portable Sawmill, SM-32; SM-36MAX (SKU: 150167; 150167K4; 150167D6; 150167K6; 150167H6; 150168MAX; 150168HMAX) $5499

( 1 Pack / 1 Pcs ) Sawmill Cover - Custom Fitted for 36" MAX Portable Sawmill, SM-36MAX; SM-36HMAX (150168MAX; 150168HMAX) $8999

Total Price

$

Product Overview

Fully capable of cutting large 36" logs and planks up to 7" wide in 1/2 the time compared to a regular chainsaw.
It comes equipped with a reliable, high-performing engine that can be used over an extended period of time.
The gearbox is belt-driven via a clutch, which smoothly transfers power from the engine to the machine; maximizing operating efficiency.
Can withstand heavy workloads for long hours, even in remote areas.
The cutting thickness of each log can be adjusted. You will have the full ability to mill the wood to any size you for your desired project.
You can manually adjust the saw head direction to have full control over the cutting process for a safer and smoother outcome.

Product manual (PDF)

150168HMAX Product Manual 1.0.pdf

Engine manual (PDF)

Honda GX690 Manual.pdf

Assembly guide (PDF)

Sawmill Quick Installation Guide.pdf

Product Features

The Honda GX690 Horizontal V-Twin OHV Engine is the ultimate powerhouse for your custom pressure washers rigs and builds. Featuring an electric start and a robust 17-amp charging system, this 688cc engine delivers an impressive 25 net horsepower, ensuring your equipment operates at peak performance. Designed with a 1-1/8’’x 3.78’’ crankshaft and an oil pressure indicator for maximum reliability, Model GX690 is the perfect engine to elevate your pressure washing and soft wash projects. Build with confidence and power up your business with Honda's unmatched quality and durability.

Electric Start

This sawmill is equipped with an electric-start Honda engine, which has excellent performance, reliable quality and can be used for a long time.

Adjustable Cutting Thickness

The handle rotates through 23 locking locations ensuring precise and consistent control. The cutting thickness can be adjusted by rotating the handle to choose the right board for you, and the maximum thickness of the board can be cut up to 7’’.

Maximum Log Diameter

This sawmill can cut a variety of logs, and can cut logs with a maximum log diameter of 36”.

Emergency Stop Button

There is an emergency stop button on the top of the log, which can stop the machine at any time in an emergency.

Maximum Cutting Width

According to the diameter of the log, the cutting width of the log can be adjusted by adjusting the length of the saw blade. The maximum cutting width is 35’’.

Throttle Handle

You can control the cutting speed by pushing this handle, and you can speed up or slow down at any time, making the wood cutting process fast and efficient, and reducing the number of steps required to meet your cutting requirements for wood boards.

Saw Blade

The saw blade made of carbonized steel is very strong, with dimensions of 175*1.3*0.04’’, and the rotation speed can be as high as 787’’ per second, which can ensure smooth and stable cutting while reducing wood chips and increasing the amount of wood.

Spiral Log Clamp

The track features easy-to-use spiral log clamps to hold logs securely while milling.

Cutting Length

The logs are equipped with a 194” standard log track, and you can purchase a 78” extension track at MechMaxx according to your needs.

Engine	HONDA GX690	Lubricant Tank Size	4gal
Engine Type	Dual Cylinder ( 90° V Type ), 4 Stroke, Forced Air Cooling	Fuel Tank Size	6.3 gal
Engine Displacement	688 cc	Track Load-Bearing	5 ton
Horsepower	25 HP	Track Width	3 ft 10 in
Start	E-Start	Track Length	20 ft
Log Diameter	36 in	Track Extension Length	6.4 ft
Max Live Edge Width	35 in	Leveling Feet	18
Standard Cutting Length	16.2 ft	Log Rests	2 Long and 2 Short Rests
Max Board Thickness	7 in	Log Clamps	2 x Quick Lock
Blade Engagement System	Centrifugal Clutch	Track Bunks	3 x 6 in
Cast Iron Bandwheel Diameter	19 in	4 Post Head Design	Yes
Blade Wheel Engagement	Belt Drive	Finish	Powder Coat Paint Galvanized Steel
Blade Guide	By Roller	Sawmill Warranty	2 Years
Blade Tension	By Adjustable Lever	Engine Warranty	2 Years
Blade Size	175 x 1.3 in	Package Method	Wood
Blade Pitch	7/8 in	Packing Size	90 x 28.5 x 34 in
Blade Lubrication	Water Lube - Manual Valve	Weight(N.W./G.W.)	1133/1257 lbs
