Engine Power Required |
18-50HP |
PTO Shaft RPM |
540 RPM |
Working Width |
72in |
Driveline Shaft Length |
T5-LF-47 With Shear Bolt ;47 - 57in |
Blade Thickness
|
0.24in |
Spline End |
1.375in z6 |
Deck Thickness |
0.16in |
3-Point Hitch |
CAT 1 |
Blade Ground Clearance |
0.4in-4in
|
Gearbox Oil Type |
85W-90 |
Max. Cutting Diameter |
Depends On The Type Of Grass
|
Dimensions (L x W x H)
|
75x 48 x 33in |
Number Of Blades |
3 |
Finish
|
Powder Coat Paint Galvanized Steel |
Drive Type |
Belt drive |
Warranty |
1 Year |
Number Of Belts |
2 |
Weight (N.W./G.W.) |
437/538lbs |
Top Link Type |
Flotation Style |
|
|
WARNlNG: This product can expose you to chemicals including engine exhaust (including diesel engine exhaust when equipped),lead and lead compounds, mineral oils, soots, phthalates, and carbon monoxide which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
Certain specification(s) are based on engineering calculations and are not actual measurements. Specification(s) are provided for comparison purposes only and are subject to change without notice. Specification(s) for your individual equipment will vary based on normal variations in design, manufacturing, operating conditions, and other factors.
