Product Overview

Sturdy 1.5 HP Motor: Delivers consistent power for a wide range of machining tasks.
Variable Speed Control: Flexibility to adjust speeds from 0–2500 RPM, ensuring precision for different materials.
Precise Threading: Capable of cutting both metric and inch threads, with a thread dial indicator for easy setup.
Durable One-Piece Spindle: Designed for long-term durability with MT#5 taper for secure tool mounting.
Versatile Swing Capacity: 8-1/4" swing over bed and 15-3/4" between centers, ideal for both small and medium projects.
Compact Design: Fits easily into smaller spaces, perfect for home or commercial workshops.

Product manual (PDF)

8'' x 16'' Metal Lathe Machine 1.0.pdf

Product Features

High-Precision 3-Jaw Chuck

This 5" 3-jaw chuck offers a strong 1.5" clamping range, ensuring secure grip and minimal runout. Designed with a MT5 spindle taper, it provides a tight, stable fit for accurate turning operations. Perfect for both small and large components, this chuck combines strength, durability, and precision.

Premium Electronic Control with Stepless Speed Adjustment

The high-quality electronic control system provides stepless speed adjustment, allowing for smooth, continuous speed changes for different workpieces. With a clear speed display, you can easily monitor and adjust settings, ensuring precise control and flexibility for all your machining tasks. Effortlessly switch between tasks and materials, and achieve the best results every time.

Precision Tool Post with Adjustable Rotation

This tool post offers superior support for turning and threading operations. With 3-1/2" cross slide travel and 2-3/4" compound slide travel, it ensures smooth, precise movements. The 60° rotation of the tool post tray allows you to easily position tools for different angles, enhancing versatility and precision in every cut. Perfect for a variety of tasks, from fine-tuning to heavy-duty operations.

Automatic Cross Feed for Precision Turning

The automatic cross feed provides smooth, hands-free movement for consistent, precise cuts. With this feature, the operator can easily adjust the feed rate, ensuring efficient and accurate machining, especially for repetitive tasks and fine surface finishes.

Quick-Lock Tailstock with Durable Aluminum Alloy Construction

This tailstock features a quick-lock design for fast, secure adjustments with minimal effort. Made from high-quality aluminum alloy, it offers durability while reducing weight. The streamlined design maintains strength without the excess material, providing an efficient and user-friendly solution for precise operations.

Precision Handwheel with Fine Adjustment

The handwheel allows for fine adjustments with precision control, perfect for tasks requiring high accuracy. Whether you're fine-tuning feed rates or making detailed cuts, this feature ensures smooth and exact movements for precise machining results.

Lathe Rails-Superior Durability & Precision

High-frequency quenching V-guide lathe rails provide exceptional wear resistance, precise fit for smooth operation, and superior impact resistance. These rails maintain high-temperature durability, reducing deformation and damage. Perfect for metalworking, they lower maintenance costs, offer eco-friendly manufacturing, and are expertly crafted with advanced technology.

Threading Dial for Precision Cutting

The threading dial indicator ensures smooth, accurate thread cutting by synchronizing the carriage with the leadscrew, preventing misalignment and enhancing thread quality. Perfect for both beginners and experienced machinists, it helps achieve flawless threads with every turn.

Integrated Safety Mechanisms with Power Disconnect

To ensure operator safety, this machine features automatic power cut-off when the chuck guard or gearbox cover is removed. This protective design prevents the machine from operating during maintenance or adjustments, reducing the risk of accidents and ensuring a safer working environment.

Motor	1.5 HP, 110V, Single-Phase, 10A, 60Hz
Swing Over Bed	8‑1/4"(210mm)
Swing Over Cross Slide	4‑5/8"(117mm)
Swing Over Saddle	3-1/2"(90mm)
Distance Between Centers	15‑3/4"(400mm)
Bed Width	4"(100mm)
Spindle Bore	1-1/2"(38mm)
Spindle Mount	Intrinsic back plate
Spindle Type	One-piece Spindle
Spindle Taper	MT#5
Tailstock Taper	MT#2
Tailstock Quill Travel	2"(50mm)
Cross Slide Travel	3-1/2"(90mm)
Compound Slide Travel	2-3/4"(70mm)
Carriage Travel	14-5/16(350mm)
Spindle Speeds	0–2500 RPM
Number of Speed Ranges	Variable
Longitudinal Feeds	0.0037-0.0068 in./rev.
Transverse Feed Rate	/
Leadscrew Size & Pitch	16mm(12TPI)
Threading Capacity - Inch	8–48 TPI（18kinds）
Threading Capacity - Metric	0.4–3.5mm(15kinds)
Maximum Tool Bit Size	15/32"(12mm)
Thread Dial Indicator	YES
Overall Dimensions	36" W x 19" D x 20" H (914 x 480 x 490 mm)
Approximate Shipping Weight	190lbs(75 kg)
