Power Required |
15-35HP |
Drive Type |
Belt drive |
Working Width |
60in |
Number of Belts |
3 |
Overall Width |
65in |
Belt Size |
V Belt 13 X 1041 |
Blade Ground Clearance |
0.6in-1.8in |
Drive Belt Tensioner |
Yes |
Max. Cutting Diameter |
0.75 in |
Deck Thickness |
0.16in |
Number Of Blades |
24 |
Side Plate Thickness |
0.24in |
Blade Type |
Hammer |
PTO Shaft RPM |
540 RPM |
Size Of Blades |
3.5 X 3 X 1.6'in |
Driveline Shaft Length |
T5-LF-31 with shear bolt ;31- 43in
|
Blade Weight |
0.8lbs |
Spline End |
1.375in z6 |
Blade (Tines)Material |
Cast Steel |
3-Point Hitch |
CAT 1 |
Rotor Bearing |
SKF bearing |
Tractor Mount |
Reversible |
Rotor Diameter |
3in |
Gearbox Oil Type |
85W-90 |
Rotor Swing Diameter |
11in |
Dimensions (L x W x H) |
65 x 30 x 28in |
Rotor Thickness |
0.3in |
Finsh |
Powder Coat Paint Galvanized Steel |
Rotor Shaft Speed |
2958 rpm |
Warranty |
1 year |
Blade Speed |
142 ft/s |
Weight (N.W./G.W.) |
673/738 lbs |
